EKO-STAR-D 30-150 watt led street light are favored by the market for their high efficiency, energy saving and long life. They provide bright and uniform lighting effects. The street lights are compact and beautiful in design, easy to install and maintain. They are widely used in public lighting places such as urban roads, parks, squares, etc.
| Housing and finish | |
| Housing | High pressure die-casting aluminum |
| Optic | PMMA/PC |
| Lens | Type l/Type ll /Type lll /Type IV/Type V |
| Protector | Super white tempered glass |
| Housing Color | Grey / black (Default), other color (available on request) |
| Protection Level | IP66 |
| Impact Resistance | IK08 |
| Warranty Time | 5 years |
| Operating conditions | |
| Operating Temperature (Ta) | -40℃ up to +55℃ |
| General information | |
| Recommended Installation Height (m) | 3~15 |
| Compliance | CE/CB/ROHS /IP66 /IK08 |
Structure is optimized by advanced FEA technology Well managed temperature rise between internaland external parts . Even thermal distributions . Higher lumen maintenance rate
| Electrical class | Classl EU ( Default), Class ll EU |
| Driver | Inventronics 1 Philips / MeanWell / MOSO / other brands one request |
| Nominal voltage | 120-277V-50-60Hz 220-240V-50-60Hz |
| Power factor (at full load) | >0.95 |
| Surge protection (kV) | 10KV( Default)/ 20KV (avalable on request) |
| Control protocol(s) | 1-10V dimming (Default) 1 Time control/ DALl |
| Control option(s) | Photocell Remote management |
| Available on request | NEMA socket(3/5/7 pins), Photocell, ZHAGA socket, Short cap, 1-10V dimming, DALl Dimming, PIR |
