EKO-STAR-B 30-150W LED solar road lights are energy-saving, environmentally friendly and highly efficient. They use 30-150W LED light sources to provide sufficient lighting brightness. The solar power supply system does not require an external power supply, which greatly reduces the operating cost. Its intelligent light control and time control functions enable the street lights to automatically switch on and off according to the ambient light, making it an ideal choice for modern urban lighting and road construction.
| Housing and finish | |
| Housing | High pressure die-casting aluminum |
| Optic | PMMA/PC |
| Lens | Type l/Type ll /Type lll /Type IV/Type V |
| Protector | Super white tempered glass |
| Housing Color | Grey / black (Default), other color (available on request) |
| Protection Level | IP66 |
| Impact Resistance | IK08 |
| Warranty Time | 5 years |
| Operating conditions | |
| Operating Temperature (Ta) | -40℃ up to +55℃ |
| General information | |
| Recommended Installation Height (m) | 3~15 |
| Compliance | CE/CB/ROHS /IP66 /IK08 |
Structure is optimized by advanced FEA technology Well managed temperature rise between internaland external parts . Even thermal distributions . Higher lumen maintenance rate
| Electrical class | Classl EU ( Default), Class ll EU |
| Driver | Inventronics 1 Philips / MeanWell / MOSO / other brands one request |
| Nominal voltage | 120-277V-50-60Hz 220-240V-50-60Hz |
| Power factor (at full load) | >0.95 |
| Surge protection (kV) | 10KV( Default)/ 20KV (avalable on request) |
| Control protocol(s) | 1-10V dimming (Default) 1 Time control/ DALl |
| Control option(s) | Photocell Remote management |
| Available on request | NEMA socket(3/5/7 pins), Photocell, ZHAGA socket, Short cap, 1-10V dimming, DALl Dimming, PIR |
