SF-9225 AC Vent Fan adopts high-efficiency motor and optimized fan blade design, which can provide strong air volume and low noise operation. Whether it is home, office or industrial plant, it can provide you with a fresh and comfortable air environment.

Specification

• Motor structure: poles of AC motor are shaded.

• Outer enclosure: high quality Al alloy, anticorrosive and anti damping structure.

• Fan blade: plastic sprayed, formed in a procedure, UL94V0 70% P.B.T.+30% F.R.P.

• Bearing structure: Oil filled bearing or ball bearing.

• Insulation level: B class.

• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.

• Dielectric strength:0.5mA 1500V/AC min.

• Safe protection:Resistance protection.

• Working temperature: oil filled type: -10℃~+45℃. Ball bearing: -20℃~+70℃.

• Storage temperature: -40℃~+70℃

• Service life: Oil: 25000h      ball: 50000h.

• Use: used in equipment of ventilation and heat
   dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.

Model Meanings
