Specification

• Motor structure: The motor capacitor drive outer rotor.

• Outer enclosure: high qualityAl alloy, anti-corrosive and anti damping structure.

• Fan blade: steel sheet formed through punching and pressing, blade welded directly on rotor of the motor, its surface treat with anti-corrosive coating by use of Cathodic electrodeposition.

• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.

• Dielectric strength: 0.5mA 1500V/AC min.

• Bearing structure: ball bearing.

• Insulation level: B, F class.

• Protection grade: lP 55.

• Safe protection: Resistance protection.

• Workingtemperature: -25℃~+85℃

• Storage temperature: -30℃~+90℃

• Service life: 50000h.

• Use: used in equipment of ventilation and heat dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.
