AC Fan SF-22082 Series

Brand:

Name:AC Fan SF-22082 Series

FOB Port:Ningbo/Shanghai/Yiwu /Guangzhou/Shenzhen
Terms of Payment:T/T
Update:07/08/2024
Description
Specification



• Motor structure: The motor capacitor drive outer rotor.

• Outer enclosure: high qualityAl alloy, anti-corrosive and anti damping structure.

• Fan blade: steel sheet formed through punching and pressing, blade welded directly on rotor of the motor, its surface treat with anti-corrosive coating by use of Cathodic electrodeposition.

• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.

• Dielectric strength: 0.5mA 1500V/AC min.

• Bearing structure: ball bearing.

• Insulation level: B, F class.

• Protection grade: lP 55.

• Safe protection: Resistance protection.

• Workingtemperature: -25℃~+85℃

• Storage temperature: -30℃~+90℃

• Service life: 50000h.

• Use: used in equipment of ventilation and heat dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.



Model Meanings





Model Bearing Rated Voltage (V) Freg (Hz) Rated Current (A) Input Power (W) Speed (Rpm) Air Flow (CMM) Air Flow (CFM) Capacity (uFN) Noise Level (dB-A) Weight (kg) Quantity (PCS)
SF-22082MBL-5 Ball 110/120 50/60 0.54/0.65 65/75 2450/2700 15.3/16.8 540/596 12uF/450V 43/46 2.95 5
SF-22082HBL-6 Ball 220/240 50/60 0.27/0.32 65/75 2450/2700 15.3/16.8 540/596 2.2uF/450V 59/61 2.95 5
