AC Fan SF-2059 Series

Brand:

Name:AC Fan SF-2059 Series

FOB Port:Ningbo/Shanghai/Yiwu /Guangzhou/Shenzhen
Terms of Payment:T/T
Update:07/08/2024
Description
Specification



• Motor structure: poles of AC motor are shaded.

• Outer enclosure: high quality Al alloy, anticorrosive and anti damping structure.

• Fan blade: plastic sprayed, formed in a procedure, UL94V0 70% P.B.T.+30% F.R.P.

• Bearing structure: Oil filled bearing or ball bearing.

• Insulation level: B class.

• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.

• Dielectric strength:0.5mA 1500V/AC min.

• Safe protection:Resistance protection.

• Working temperature: oil filled type: -10℃~+45℃. Ball bearing: -20℃~+70℃.

• Storage temperature: -40℃~+70℃

• Service life: Oil: 25000h      ball: 50000h.

• Use: used in equipment of ventilation and heat
   dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.



Model Meanings





Model Bearing Rated Voltage (V) Freg (Hz) Rated Current (A) Input Power (W) Speed (Rpm) Air Flow (CMM) Air Flow (CFM) Static Pressure (mmH₂O) Noise Level (dB-A) Weight (G) Quantity (PCS)
SF-2509HBL-2 Ball 220/240 50 0.35 72 2700 20 740 0.78/0.82 72 2350 10
