• Motor structure: The motor capacitor drive outer rotor.
• Outer enclosure: high qualityAl alloy, anti-corrosive and anti damping structure.
• Fan blade: steel sheet formed through punching and pressing, blade welded directly on rotor of the motor, its surface treat with anti-corrosive coating by use of Cathodic electrodeposition.
• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.
• Dielectric strength: 0.5mA 1500V/AC min.
• Bearing structure: ball bearing.
• Insulation level: B, F class.
• Protection grade: lP 55.
• Safe protection: Resistance protection.
• Workingtemperature: -25℃~+85℃
• Storage temperature: -30℃~+90℃
• Service life: 50000h.
• Use: used in equipment of ventilation and heat dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.
Model | Bearing | Rated Voltage (V) | Freg (Hz) | Rated Current (A) | Input Power (W) | Speed (Rpm) | Air Flow (CMM) | Air Flow (CFM) | Capacity (UF/VDB) | Noise Level (dB-A) | Weight (G) | Quantity (PCS) |
SF-200FZY2-D | Ball | 220/240 | 50/60 | 0.30 | 65 | 2500 | 13.0 | 459 | 1uF/450V | 70 | 2000 | 10 |
SF-200FZY3-D | Ball | 380 | 50/60 | 0.15 | 65 | 2500 | 13.0 | 459 | 70 | 2000 | 10 | |
SF-200FZY4-D | Ball | 380 | 50/60 | 0.16 | 65 | 2500 | 13.0 | 459 | 0.47uF/630V | 70 | 2000 | 10 |
