SF-13532 small AC fan is a high-efficiency and energy-saving heat dissipation equipment, the fan uses high-quality motors and fan blades, stable speed, strong wind, can quickly reduce the temperature of the equipment, to ensure the normal operation of the equipment. Its compact size and light weight make it easy to install and suitable for heat dissipation needs in various occasions. The SF-13532 small AC fan also has the advantages of low noise and long life, making it an ideal choice for heat dissipation in electronic devices.

Specification

• Motor structure: poles of AC motor are shaded.

• Outer enclosure: high quality Al alloy, anticorrosive and anti damping structure.

• Fan blade: plastic sprayed, formed in a procedure, UL94V0 70% P.B.T.+30% F.R.P.

• Bearing structure: Oil filled bearing or ball bearing.

• Insulation level: B class.

• Insulation resistance: more than 100MΩ between outer enclosure and windings applied with 500VDC.

• Dielectric strength:0.5mA 1500V/AC min.

• Safe protection:Resistance protection.

• Working temperature: oil filled type: -10℃~+45℃. Ball bearing: -20℃~+70℃.

• Storage temperature: -40℃~+70℃

• Service life: Oil: 25000h      ball: 50000h.

• Use: used in equipment of ventilation and heat
   dispersion Places, such as electrical control cabinet, machine tool, EPS, UPS, Medical equipment needs ventilation cooling.

Model Meanings
